In today’s fast-paced industrial environments, skid-mounted process control panels offer a compact, efficient, and ready-to-install solution for automating complex systems. These panels are pre-wired, pre-tested, and integrated onto structural skids, providing plug-and-play control for a wide range of applications.
What Are Skid-Mounted Control Panels?
A skid-mounted control panel is an electrical control unit installed on a structural frame (or skid) that includes all necessary components—wiring, instrumentation, piping, and controls—pre-assembled and tested before delivery.
Key Advantages of Skid Panels
- Modular Design – Easy to transport, install, and scale.
- Reduced Installation Time – Arrives fully assembled and tested.
- Improved Quality Control – Fabricated in a controlled environment.
- Lower Cost of Ownership – Minimizes on-site labor and downtime.
Typical Components in a Skid System
- PLC and HMI Interfaces
- Temperature and Pressure Sensors
- VFDs (Variable Frequency Drives)
- Motor Starters and Contactors
- Field I/O and Terminal Blocks
Applications of Skid-Mounted Systems
- Oil & Gas – For wellhead automation, chemical injection, and pump controls.
- Water & Wastewater – Used in filtration, disinfection, and pumping systems.
- Food & Beverage – Automates mixing, batching, and temperature regulation.
- Pharmaceutical & Chemical – Ensures precise dosing and safe material handling.
Compliance and Safety
Skid-mounted panels can be built to meet UL 508A, UL 698A, and hazardous location standards such as NFPA 496 or ISA 12.12.01, ensuring safety and regulatory compliance.
If your project needs fast deployment, custom automation, and compliance with industry standards, skid-mounted process control panels are the solution. At I&I Soft Craft Solutions, we design, build, and test complete skid systems tailored to your industrial process.
Let’s build your next turnkey automation system—contact I&I Soft Craft Solutions today!
